Kenya OPGW-12B4-226 [93.8;496.1] Price from Manufacturer in China
Cable Type: OPGW-12B4-226 [93.8;496.1]
Power Line Fiber Optic Cable Types:
Such cable (OPGW ADSS OPPC ) combines the functions of grounding and communications.
OPGW: Dual performance of ground wires with communication capabilities.
OPPC: Dual performance functions of phase conductors with communication capabilities.
ADSS: Non-metallic self-supporting optical fiber cables directly between two power towers.
OPLC: Optical fiber composite insulated power cable for low voltages is a new type of optical fiber composite cable for low-voltage power lines
OPGW-12B4-226 Structure
| Structure |
|
Material |
No |
Material |
No. |
Material Dia. |
| Fiber |
G.655 |
OPGW 12 |
|
|
|
| Center |
40%AS wire |
1 |
|
|
Diameter |
4.00 |
mm |
| Layer1 |
40%AS wire |
5 |
|
|
Diameter |
4.00 |
mm |
| |
SUS Tube |
1 |
Fibers(all tube) |
12 |
Tube-Dia. |
3.90 |
mm |
| Layer2 |
AA wire |
12 |
|
|
Diameter |
4.00 |
mm |
OPGW-12B4-226 Technical Data
Technical Data |
According to IEC, IEEE standards |
| stranding direction of outer layer is right hand(Z-stranding) |
| Cable Diameter |
20.00 mm |
| Cable Weight |
794.0 kg/km |
| Supporting Cross Section |
226.19 mm2 |
| Section of AS W ire 75.40 mm2 |
| Section of AA Wire 150.80 mm2 |
| Rate Tensile Strength (RTS) |
93.50 kN |
| Modulus of Elasticity (E-Modulus) |
79.7 kN/mm2 |
| Thermal Elongation Coefficient |
19.6 × 10-6/C |
| Permissible Maximum Working Stress (40% RTS) 165.3 N/mm2 |
| Everyday Stress (EDS) ( 18%~25% RTS) 74 4 ~ 103 3 N/mm2 |
| Ultimate Exceptional Stress (70% RTS) |
289.4 N/mm2 |
| DC Resistance |
0.164 Ω/km |
| Short Time Current |
(0.5s, 20C~200C) |
31.5 kA |
| Short Time Current Capacity I2t |
496. 1 kA2S |
| Minimum Bending Radius： Installation： |
400 mm |
| Oprating： |
300 mm |
| Temperature Range: |
Installation |
- 10C ~ +50 C |
| Transportation and Operation |
-40C ~ +80 C |
